Overloaded vector inverter

This customized overloaded vector inverter integrates multifunctionality, featuring an  electrolytic capacitor and a built-in cooling fan for stable operation. With intelligent speed control and constant pressure water supply, it ensures energy efficiency. The LED display offers intuitive control, making it ideal for diverse industrial applications.

Request a Quote

Description

Product Introduction

This customized overloaded vector inverter is a high-performance device designed to meet diverse industrial needs. It features a multifunctional all-in-one design with stable  electrolytic capacitors, flame-retardant composite plastic, and a built-in cooling fan for enhanced durability and safety. The inverter offers intelligent speed control, constant pressure water supply, and energy-saving capabilities. Its LED display ensures intuitive operation, making it ideal for various applications.

Use

This customized overloaded vector inverter is suitable for a wide range of industrial environments. It excels in applications requiring precise motor speed control, such as in manufacturing plants, water supply systems, and HVAC systems. Its robust design, featuring a strong cooling fan and multi-hole heat dissipation, ensures reliable operation even in harsh conditions. The inverter’s energy-saving capabilities also make it ideal for environmentally conscious operations.

Product parameters

Voltage
level
Power(kw)Size and weight dataCase style
Gross         weight      (kg)External      dimensions       (High * wide * deep)Installation dimensions    (High * wide)Packing            box size         (High * wide * deep)
380V0.752.0180*120*158110.4*170.2240*173*220Plastic Shell
380V1.52.0Plastic Shell
380V2.22.0Plastic Shell
380V4.03.8250*160*183147.5*237.5315*207*246Plastic Shell
380V5.53.9Plastic Shell
380V7.54.2Plastic Shell
380V116.6320*220*190205*305380*275*245Plastic Shell
380V156.7Plastic Shell
380V18.511.5395*250*190200*380455*340*275Sheet metal     in and out
380V2217.3465*290*220175*445547*380*300Sheet metal     in and out
380V3018.5Sheet metal     in and out
380V3719.0470*290*250175*450545*385*330Sheet metal     in and out
380V4520.9Sheet metal     in and out
380V5522.0Sheet metal     in and out
380V7529.6550*290*275230*565650*380*370Sheet metal     in and out
380V9053.0670*330*325(Hang up)                                                                                                                        870*330*325(cabinet)240*640680*380*375Sheet metal     in and out
380V11053.0Sheet metal     in and out
380V13255.0Sheet metal     in and out
380V16073.5750*460*330(Hang up)   950*460*330(cabinet)315*725780*530*370Sheet metal     in and out
380V18589.0860*500*360(Hang up)     1210*500*360(cabinet)400*830880*570*390Sheet metal     in and out
380V20090.6Sheet metal     in and out
380V220175            (Not accurately measured)1160*660*370(Hang up)                  1510*660*370(cabinet)400*11301185*745*420Sheet metal     in and out
380V250Sheet metal     in and out
380V285Sheet metal     in and out
380V315Sheet metal     in and out
380V355225             (Not accurately measured)1340*700*435(Hang up)                 1690*700*435(cabinet)400*13001355*780*470Sheet metal     in and out
380V400Sheet metal     in and out
380V450Sheet metal     in and out
380V500Sheet metal     in and out

Product Features

  • This customized overloaded vector inverter features a multifunctional all-in-one design. With an EPCOS electrolytic capacitor, it ensures stable charging and discharging. The composite flame-retardant plastic offers safety, and the built-in cooling fan maintains optimal temperature, enhancing service life.
  • Our custom overloading vector inverter provides wide application scope. It achieves intelligent motor speed control and constant pressure water supply control. This inverter not only regulates speed but also saves energy, reduces emissions, and improves production efficiency effectively.
  • The customized overloaded vector inverter boasts multiple functions in one table. It includes multi-mode regulation, energy and power saving, a 2-year warranty, step-less speed regulation, protective motor features, and convenient operation. It’s designed for flexible control and easy equipment adjustment.
  • This custom-made overloaded vector inverter has an LED display for intuitive operation and high work efficiency. Its strong cold fan enables multi-hole heat dissipation, ensuring powerful and efficient cooling. With stronger load-bearing capacity, it offers better stability for diverse applications.
  • Our tailored overloaded vector inverter emphasizes constant pressure water supply, energy, and electricity saving. It features flexible control for easy equipment adjustment. The strong cold fan with multi-hole heat dissipation ensures efficient cooling, while the LED display provides an intuitive interface for users.
Note:
  1. Read the manual thoroughly before use. Avoid connecting power to output terminals and ensure proper grounding. Wait 10 minutes after power-on for capacitors to discharge before maintenance.

  2. Regularly check and maintain the inverter, ensuring good ventilation. Keep it away from flammable materials and verify smooth fan operation. Replace damaged parts promptly.

Product installation and instructions

  1. Unboxing and Inspection:Unpack and inspect the inverter for damage. Verify all components against the inventory list.

  2. Mounting:Install the inverter in a ventilated area away from heat. Secure it with fasteners, allowing space for airflow and maintenance.

  3. Electrical Connections:Connect the power supply and motor to the inverter as per specifications. Ensure secure connections to avoid loose contacts.

  4. Control Wiring:Wire control devices to the inverter, adhering to the diagram. Confirm correct polarity and signal types.

  5. Testing:Power on the inverter and test functionality. Monitor for abnormalities and ensure it meets operational requirements.

Product images

Overloaded vector inverter Overloaded vector inverter Overloaded vector inverter Overloaded vector inverter Overloaded vector inverter Overloaded vector inverter
