Industrial Pneumatic Fan BTF

The Industrial Pneumatic Fan BTF is a high-efficiency ventilation solution powered by compressed air, making it ideal for environments where electrical equipment is unsuitable. Its robust design ensures reliable performance and durability, even in demanding industrial settings.

Highlights

  • Pneumatic Power System: Operates using compressed air, making it ideal for environments where electrical equipment is restricted.
  • High-Performance Ventilation: Provides strong airflow for effective cooling and ventilation in industrial applications.
  • Durable and Safe Design: Built with robust materials to ensure reliability and safety in demanding working conditions.

Product Details

Product Introduction

Pneumatic fan BTF is an efficient and energy-saving pneumatic driven ventilation equipment. It adopts advanced pneumatic technology, does not require electric drive, relies on the energy of compressed air or gas to generate power, thereby driving the rotation of fan blades and achieving air circulation. BTF pneumatic fans have the characteristics of simple structure, light weight, easy installation, smooth operation, and low noise. They are suitable for various places that require ventilation and air exchange, such as factory workshops, warehouses, basements, etc. At the same time, it also has explosion-proof, anti-corrosion and other characteristics, which can meet the ventilation needs in special environments, making it an ideal ventilation equipment.

Features:

Explosion-proof pneumatic fan, taking compressed air as apower supply and selecting explosion-proof pneumatic motor as power device.

It consists of pneumatic motor,impeller,silencer, air duct and controller etc.,

Enough gas drives the impeller running,it can control the speed of fan by adjusting air throttle valve realizes different capacity and static,as well as saving and highly efficient using energy.

Pneumatic fan advantage:

  1. It can run for 365 days, no fever and no spark.
  2. Choose pneumatic motor as power plant, it will be strong power, good performance in explosion-proof.
  3. Choose compressed air as the power source,Energy efficient, One unit air compressor can supply for several pneumatic fans.

It’s widely used in vessel, chemical factory, paint workshop and gas station etc.

It can be used with or without Ventilator Tube in hazardous areas such as cooling tanks or hatches.They provide ventilation of gas, paint fumes and other hazardous fumes.

Model Diameter

(mm)

Air consumption(m3/h) Air volume(m3/h) Air pressure(mpa) Speed(r/min) Noise(dB) Tracheal diameter
BTF-II-30 300(12’’) 1.0 3900 0.6 3000 69 Φ12
BTF-II-35 350(14’’) 1.0 4500 0.6 2600 69 Φ12
BTF-II-40 400(16’’) 2.2 6300 0.6 2200 79 Φ16
BTF-II-45 450(18’’) 2.2 7100 0.6 1800 79 Φ16
BTF-II-50 500(20’’) 2.2 9000 0.6 1500 73 Φ16
BTF-II-60 600(24’’) 2.2 14700 0.6 1300 75 Φ16
BTF-II-70 700(28’’) 2.2 17700 0.6 1200 75 Φ16

BTF Serial Size And Mounting Size:

INSTALLATION SIZE

Model no D1 D2 H1 H2 A A1 A2 A3 B1 B2
BTF-II-30 Φ335 Φ380 425 220 380 265 225 60 265 220
BTF-II-35 Φ385 Φ430 480 250 380 265 225 50 300 240
BTF-II-40 Φ435 Φ480 520 280 400 285 245 50 320 265
BTF-II-45 Φ465 Φ510 550 310 430 285 245 50 340 285
BTF-II-50 Φ535 Φ580 620 330 400 285 245 50 370 310
BTF-II-60 Φ635 Φ690 730 380 420 305 265 50 460 365
BTF-II-70 Φ735 Φ790 830 430 420 305 265 50 510 415

Precautions:

  • Before use, it is necessary to first add specialized white oil for pneumatic operation before use (otherwise the pneumatic motor may get damp, water, rust, and become stuck in operation)
  • Add oil to the position of the oil pointer on the right oil cup (after adding it, be sure to rotate the button above to adjust the oil volume to the minimum)
  • Adjust the intake valve to maximum (the large black rotation on the top left of the pressure gauge should be lifted first and then rotated to maximum)
